Relay mini 12V DC 3A 1Pin NO (SPST-NO) G5NB-1A4-12DC Omron
-17%
Προβολή
SPECIFICATION
Contacts configuration SPST-NO
Rated coil voltage 12V DC
AC contacts rating @R 3A / 125V AC
DC contacts rating @R 3A / 30V DC
Contact current max. 3A
Switched voltage max. 30V DC, max. 250V AC
Mounting PCB
Coil resistance 720Ω
Operate time 10ms
Body dimensions 20.5x7.2x15.3mm
Release time 10ms
Coil power consumption 200mW
Operating temperature -40...70°C
Relay series G5NB
Contact resistance 100mΩ
Terminal pitch 7mm
Coil current 16.7mA
Enclosure description hermetic seal
