Relay mini 9V DC 10A 1pins SPDT G5LE-14-9 Omron
Προβολή
Specifications
Type of relay electromagnetic
Contacts configuration SPDT
Rated coil voltage 9V DC
AC contacts rating @R
(at resistive load) 10A / 240V AC
DC contacts rating @R
(at resistive load) 8A / 30V DC
Contact current max. 10A
Switched voltage max. 125V DC, max. 250V AC
Relay variant miniature
Mounting PCB
Coil resistance 200Ω
Operate time 10ms
Body dimensions 22.5x16.5x19mm
Release time 5ms
Coil power consumption 400mW
Operating temperature -40...85°C
Relay series G5LE
Contact resistance 100mΩ
Terminal pitch 2mm
Coil current 45mA
Enclosure description hermetic seal
