Πεδιόμετρο DVB-C/S2/T2 P9020 PeakTech

 Οδηγίες Χρήσης
 Τεχνικές προδιαγραφές

The PeakTech 9020 is a comprehensive multifunction measuring device for channel levels from DVB systems. Channel searches for cable, satellite or terrestrial systems can be carried out, channel lists can be created and managed, or satellite systems can also be aligned. This measuring device is supplied with a carrying case and measuring case in addition to a wide range of accessories and is ideal for the electronics engineer and service technician.

Note: The PeakTech 9020 uses H.264 Video Decoder for DVB-T2 (e.g. France, Austria) - Germany uses the H.265 standard which is not compatible
12.5 cm (5 ") color TFT display with 320 x240 pixels
DVB-C, DVB-S & S2, DVB-T & T2 Program search
Live TV display with sound
Spectrum analyzer for all DVB functions
Built-in TV recording function in the receiver format
16QAM to 256QAM and QPSK / 8PSK demodulator
Fast 450 MHz processor and 256 MB SDRAM
HDMI & AV-IN/OUT, and USB ports
Video Decoder with 576i to 1080p scaling
Safety: EN 60950-1
Accessories: Metal case, AC adapter, Li-ion battery, adapter 12 car, Software for Windows XP/VISTA/7/8/10, remote control, video cable, holster, carrying strap and manual
Additonal Accessories: Battery pack 11,1 V/2600 mAh, model AKKU 7

USB: ■
Battery: Li-Ion 2600 mAh
DVB-program: DVB-C, DVB-C2, DVB-S, DVB-S2, DVB-T, DVB-T2
Display Type: Color-TFT
HDMI: ■
Info-LEDs: ■
LED-lamp: ■
Live-TV: ■
Mains voltage: 110/240 V AC; 50/60 Hz
Resolution: 320 x 240 Pixel
Screen size (TFT): 12,5 cm (5")
Video recording: ■
