Ενισχυτής ιστού 1xUHF/DAB Gain 30dB MFA 617 TRIAX

TRIAX mast electronics includes easy-to-mount high performance range of mast amplifiers w/ F-connectors.
The MFA range are multiband amplifiers featuring 1-2-3 inputs and 1-2 outputs; as well as cut off channels Ch 49...69 & Ch 60...69

Powered by 24 VDC
LTE protected (700 & 800 models)
Higher output level
High shielding
Corrosion resistent
Flip/lock mechanism for easy installation
Neoprene soft cable grip
Weatherproof housing
Supplied w/ F-connector tool
RF shielded & CE approved (EN50083)

CONNECTORS
Number of inputs: 1
Number of outputs: 2
Impedance: 75 Ω

FREQUENCY RANGE
Band: DAB / DAB+ / UHF
Input 1 - frequency: 174...230 / 470...694 MHz
Input 1 - channels: 5...12 / 21...48
LTE protection; @ 700Mhz

GAIN
Input 1 - gain: 10...25 / 15...30 dB
Input 1 - noise figure: <4.0 dB
Return Loss: 10 dB
Max. Output level (@ -60dB IMD): 104 dBµV

OPERATIONAL
LED indicator: Green
DC Operating voltage: 24 VDC
DC Current consumption: 45 mA
***The power supply not included
