Transistor TIP31C
Αναμένεται Σύντομα
Προβολή
Specifications
Manufacturer: ON Semiconductor
Product Category: Transistors Darlington
RoHS: No
Configuration: Single
Transistor Polarity: NPN
Collector- Emitter Voltage VCEO Max: 80 V
Emitter- Base Voltage VEBO: 5 V
Collector- Base Voltage VCBO: 80 V
Maximum DC Collector Current: 8 A
Maximum Collector Cut-off Current: 200 uA
Power Dissipation: 70 W
Maximum Operating Temperature: + 150 C
Mounting Style: Through Hole
Package/Case: TO-220-3
Packaging: Tube
Continuous Collector Current: 8 A
DC Collector/Base Gain hFE Min: 500
Minimum Operating Temperature: - 65 C
