Σταθμός θερμού αέρα WHA 3000PS Set T0053355699N Weller

 Τεχνικές προδιαγραφές

WHA 3000PS

Integrated turbine
Set with Infrared preheating plate and circuit board holder
Hot Air Station Set, 700 W

Dimensions W x D x H (mm): 240 x 270 x 170 (WHA3000P)
Voltage: 220-230V/50-60Hz
Air consumption l/min: X
ESD-safe
Heating output: 700 W
Thermocouple port: 1x Type-K
Temp. accuracy top heater: ± 30 °C (± 54 °F)
Optical placement system: X
Temp. range / Bottom Heater (°C): 50 - 400
Temp. range / Top Heater (°C): 50 - 500
Nominal power bottom heater (W): 600
Nominal power top heater (W): 700
Power consumption: 1200 W
Max. air flow rate l/min: 5 - 50
Compressed air kPa/bar: X
Compressed air connection / remark: X
Compressed air connection: X
Recommended component size (mm) :4,5 x 4,5 - 43x43
Recommended PCB sice (mm) :310 x 320
Workspace L x B x H (mm) :600 x 600 x 500 (WHA3000P + WBHS + WHP3000)
Workspace L x B x H (Inch): 23,6 x 23,6 x 19,7 (WHA3000P + WBHS + WHP3000)
Dimensions W x D x H (inch): 9,44 x 10,63 x 6,69
WT compatible
