Relay mini 60V AC 15A max DPDT 2pins 40.52.8.060.0000 FINDER
-23%
Προβολή
Specification
Manufacturer FINDER
Type of relay electromagnetic
Contacts configuration DPDT
Rated coil voltage 60V AC
Contact current max. 15A
AC contacts rating @R(at resistive load) 8A / 250V AC
DC contacts rating @R(at resistive load) 8A / 30V DC
Switched voltage max. 220V DC, max. 400V AC
Relay variant miniature
Mounting PCB, socket
Coil resistance 2.1kΩ
Coil power consumption 1.2VA
Operating temperature -40...85°C
Relay series 40.52
Contact material AgNi
Terminal pitch 5mm
Coil current 16.8mA
Body dimensions 29x12.4x25mm
Gross weight16.81 g
