Relay mini 2.2V DC 5A 1Pins 1 CO PE014F02 Tyco Scrack

 Τεχνικές προδιαγραφές

DESCRIPTION

Supplier: TE Connectivity / P&B Brand
Part No: PE014F02
RoHS: Unknown
Relay Construction: Latching Single Coil
AC Coil Voltage: N/A
DC Coil Voltage: 2.2 V
Contact Arrangement: SPDT
Maximum Current Rating: 5 A
Mounting: Through Hole
Termination Style: PC Pin
Push to Test Button: No
Led Indicator: No
Operating Temperature: -40 to 85 °C
Coil Power Rating Class (mW): 200 – 300
Coil Power Rating DC (mW): 220
Coil Resistance (Ω): 22

Electrical Characteristics

Coil Voltage Rating (VDC): 2
Contact Switching Voltage (Max) (VAC): 400
Contact Voltage Rating (VAC): 250
Insulation Creepage Between Contact & Coil : 4 mm [ .157 in ]
Insulation Initial Resistance (MΩ): 10000000

Dimensions

Product Height : 10 mm 
Product Length : 20 mm
Product Width : 10 mm
