Συχνόμετρο πάγκου 1.3GHz / 1μse ακριβείας MS6100 MGL Mastech

 Τεχνικές προδιαγραφές

Συχνόμετρο πάγκου 1.3GHz / 1μse για μετρήσεις υψηλής ακρίβειας.

Χαρακτηριστικά:

Μετρητής συχνότητας

High Display Resolution: 8-digit, 22000-count red LED display.
Wide Frequency Range: Measures up to 1300MHz.
Low Pass Filter: Effective for reducing high-frequency noise.
OSC Output: 10MHz standard output.
Data Hold: Retains measurement values for analysis.
Self-Check Function: provides a means of verifying proper overall operation of counter.
Overrange Indications: Alerts users to measurement limits.
Relative Measurement: Eliminate low resistance or impedance on the test leads during measurements.
Safety Certified: CAT III 300V rating for safe operation.
Specifications:

Frequency Range: 10Hz to 1300MHz
Resolution: Selectable from 1Hz to 10kHz
Input Impedance: Channel A (1MΩ), Channel B (50Ω)
Max Input Voltage: 250V RMS (Channel A), 3V RMS (Channel B)
Benefits:

Versatility: Suitable for a wide range of frequency measurements.
Ease of Use: Simple interface with a clear LED display and data hold function.
Reliability: Robust design with self-check and overrange indicators.εύρους μέτρησης (OverRange)
•Ταλαντωτής OSC. Out 10MHz
