Μεγάφωνο woofer 10'' 8Ω 500W 10-PE26 B&C

 Τεχνικές προδιαγραφές

Overview
The B&C Speakers 10MD26 10" midbass driver boasts a blisteringly loud sensitivity rating of 100 dB 1W/1m, which combined with its substantial 350 watts RMS power rating makes it capable of generating a lot of output!

Highlights

Very high efficiency
3" lightweight aluminum voice coil
350 watts RMS power handling
Great for horn loaded designs

power handling (continuous/programme) = 250/500 W
resonance frequency fs = 51 Hz
impedance R = 8 Ohm
sound pressure level SPL = 101,5 dB (2,83V; 1m)
DC resistance Re = 5,8 Ohm
force factor BL = 19,1 N/A
voice coil inductance L = 1,4 mH
effective piston radiating area Sd = 296 cm2
effective mechanical mass incl. air load 37 g
equivalent volume of compliance Vas = 101 l
total Q factor Qts = 0,19 (Qms=7,6, Qes=0,19)
maximum peak linear excursion vibration xlin = +/- -2,8 mm
mounting diameter d = 282 mm
overall diameter d = 316 mm
mounting depth (not countersunk) t = 135 mm
