Κονέκτορας υψηλής ισχύος 10mm 110A SBS series 1pcs 1339G5 Anderson Power

Specifications

The patented SBS® connector family is designed toprovide high power in a compact ergonomic housing with protection against accidental contact with live circuits.This is of particular importance in applications where DC voltages exceed 30 volts and can be healththreatening.
Wire-to-wire and wire-to-board configurations bothprovide power contacts rated up to 110 amps. TheSBS®75X offers up to 4 mate-last break-first auxiliarypower / signal contacts rated up to 20 amps. TheSBS®75G features a third first-mate last-break groundor power contact. All contact positions are rated forcircuit interruption (hot plugging).
Touch Safe Interface
Can safely be used in through panel applications
Minimizes potential contact with live circuits per IEC 60950
Wire-to-Wire and Wire-to-Board Configurations
Allows one connector to meet multiple needs
Ground or Auxiliary Positions Integrated into the One Piece Housing
Meets all connection requirements in one compact connector housing

** Προσοχή, συσκευασία 1 τεμαχίου πωλείται ανά συσκευασία, για την συνδεσμολογία με τα housing SBS απαιτούνται 2 τεμάχια .
