Κονέκτορας N θηλυκός -> καλώδιο 1/2'' CHF-12NF LG LS Intustrial System

 Τεχνικές προδιαγραφές

DESCRIPTION

• Excellent V.S.W.R Performance
• Very Low intermodulation
• Pre-Assembled Single-Part Design for Fast and Easy installation
• Waterproof
• Environment Resistance Ensures Long Life and Consistent Performance

SPECIFICATION

Model. CHF 12NM / CHF 12NF
Transmission Line Type Coaxial Cable
Cable Size 1/2”
Cable Type HFC 12D
Mating Interface N-Type
Gender Male and Female
Material / Plating Outer Conductor / Coupling Nut Brass / Three Material Alloy (Cu-Zn-Sn) / Ni
Material / Plating Center Conductor Brass (Male), Beryllium Copper (Female) / Silver
Material / Insulator PTFE
Material / Gasket Silicone Rubber
Frequency DC ~ 3Ghz
Return loss (VSWR) DC ~2.7Gh : ≥28.3 (VSWR =1.08)
2.7Gh ~ 3Ghz : ≥26.4 (VSWR =1.10)
Impedance (Ohm) 50Ω
Insertion Loss (dB) -0.05x√f (f=GHz)
IMD(20W X 2-tone) ≤-155 dBc
Insulation Resistance (MOhm) ≥5,000
Contact Resistance (MOhm) Inner Contact ≤1.0mΩ
Outer Contact ≤1.0mΩ
Coupling Nut Torque 0.68 ~ 1.70 Nm
Weight (Male / Female) 76g / 78g
Temperature Range -40 ~ + 85℃
Waterproof IP68
