IC SN74LS42N PDIP-16 Encoders Decoders Multiplexers & Demultiplexers 4 to 10 BCD

Specifications

Number of Input Lines: 4 Input
Number of Output Lines: 10 Output
Propagation Delay Time: 30 ns
Supply Voltage - Max: 5.25 V
Supply Voltage - Min: 4.75 V
Minimum Operating Temperature: 0 C
Maximum Operating Temperature: + 70 C
Mounting Style: Through Hole
Function: 4 to 10 BCD
Height: 4.57 mm
High Level Output Current: - 0.4 mA
Input Voltage: 2.0 V to 0.8 V
Length: 19.3 mm
Logic Type: Decoder
Low Level Output Current: 8 mA
Maximum Clock Frequency: 35 MHz
Number of Circuits: Dual
Operating Supply Voltage: 5 V
Operating Temperature Range: 0 C to + 70 C
Output Current: 8 mA
Output Voltage: + 0.4 V to + 0.5 V
Supply Current - Max: 7 mA
Technology: Bipolar
Width: 6.35 mm
Unit Weight: 1 g

Package/Case: PDIP-16
