IC Counter ICs 3 V to 18 V PDIP-16 CD4040BEE4 Texas Instruments
-21%
Προβολή
Specification
Pin 16
Package Type N
Industry STD Term PDIP
JEDEC Code R-PDIP-T
Bits 12
F @ Nom Voltage(Max) 8 Mhz
Function Counter
ICC @ Nom Voltage(Max) 0.03 mA
Operating Temperature Range -55 to 125 C
Output Drive (IOL/IOH)(Max) 1.5/-1.5 mA
Package Group PDIP
Package Size: mm2:W x L See datasheet (PDIP) PKG
Technology Family CD4000
Type Binary
VCC(Max) 18 V
VCC(Min) 3 V
Voltage(Nom) 5,10,15 V
tpd @ Nom Voltage(Max) 160 ns
Width (mm) 6.35
Length (mm) 19.3
Thickness (mm) 3.9
Pitch (mm) 2.54
Max Height (mm) 5.08
