Φωτοκύτταρο παραλληλόγραμμο αυτοανάκλασης NPN 0-2m 12-24V DC BA2M-DDT Autonics

 Τεχνικές προδιαγραφές

Specification

BA2M-DDT

Sensing type : Diffuse reflective type
Sensing distance : 2m
Sensing target : Opaque, Translucent material
Light source : Infrared LED(850nm)
Response time : Max. 1ms
Power voltage : 12-24VDC specialstring ±10%(ripple P-P: max. 10%)
Operation mode : Light ON
Control output : NPN open collector

Data sheet

Sensing type Diffuse reflective type
Sensing distance 2m
Sensing target Opaque, Translucent material
Light source Infrared LED(850nm)
Response time Max. 1ms
Power voltage 12-24VDC specialstring ±10%(ripple P-P: max. 10%)
Current consumption Max. 15mA
Sensitivity adjustment Sensitivity adjuster
Operation mode Light ON
Control output NPN open collector
Connection type Cable type(Ø3, 2m)
Environment_Ambient illumination Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination)
Environment_Ambient temperature -25 to 55℃, storage: -25 to 70℃
Protection structure IP64
Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH
Hysteresis(distance) Max. 20% at sensing distance
Material Case: Acrylonitrile butadiene styrene, Sensing part: Polycarbonate, Indicator: Polycarbonate, Adjuster: IXEF
Accessories Adjuster driver

Weight Approx. 50gr
