Ενισχυτής ιστού 1xUHF/DAB - 1xFM Gain 35dB MFA 627 TRIAX

TRIAX mast electronics includes easy-to-mount high performance range of mast amplifiers w/ F-connectors.
The MFA range are multiband amplifiers featuring 1-2-3 inputs and 1-2 outputs; as well as cut off channels Ch 49...69 & Ch 60...69

Powered by 24 VDC
LTE protected (700 & 800 models)
Higher output level
High shielding
Corrosion resistent
Flip/lock mechanism for easy installation
Neoprene soft cable grip
Weatherproof housing
Supplied w/ F-connector tool
RF shielded & CE approved (EN50083)

CONNECTORS
Number of inputs: 2
Number of outputs: 1
Impedance: 75 Ω

FREQUENCY RANGE
Band: FM / DAB / DAB+ / UHF
Input 1 - frequency: 174...230 / 470...694 MHz
Input 1 - channels: 5...12 / 21...48
Input 2 - frequency: 87...108 MHz
Input 2 - channels: FM
LTE protection: @ 700Mhz

GAIN
Input 1 - gain: 20...35 dB
Input 1 - noise figure: 2.5 (@174...230MHz) 2.0 (@470...694Mhz) dB
Input 2 - gain: 12...22 dB
Input 2 - noise figure: 2.5 dB
Return Loss: 10 dB
Max. Output level (@ -60dB IMD): 108 dBµV

OPERATIONAL
LED indicator: Green
DC Operating voltage: 24 VDC
DC Current consumption: 43 mA
***The power supply not included
