Διακλαδωτής τηλεοπτικού σήματος 75Ω 3 εξόδων 5 -> 2.4GHz SCS 3 Fagor

 Τεχνικές προδιαγραφές

SCS 3, 3-way splitter, 5-2.4GHz

TRIAX coaxial splitter ideal for SAT-IF and MATV distribution networks.

FREQUENCY RANGE
Frequency range 5...2400 MHz

OPERATIONAL
Application SAT-IF, MATV 2.4Ghz +DC(out->in)
Screening Efficiency EN50083-2 (Class A)
DC Passthrough Yes (max. 0.5A/24V)
Certification EN 50581:2012 (RoHS II)
Environment Indoor
Temperature - operating -30…+60 °C

LOSS
Insertion loss (in-out) 5-40 Mhz 6.5 dB
Insertion loss (in-out) 40-1000 Mhz 7.5 dB
Insertion loss (in-out) 1000-2150 MHz 10.0 dB
Insertion loss (in-out) 2150-2400 Mhz 10.5 dB

ISOLATION
Isolation (tap-tap) 5-40 MHz 23 dB
Isolation (tap-tap) 40-1000 MHz 22 dB
Isolation (tap-tap) 1000-2150 MHz 23 dB
Isolation (tap-tap) 2150-2400 MHz 23 dB

RETURN LOSS
Return loss (in-out) 5-40 MHz 10.0 dB
Return loss (in-out) 40-1000 MHz 12.0 dB
Return loss (in-out) 1000-2150 MHz 13.0 dB
Return loss (in-out) 2150-2400 MHz 13.0 dB

CONNECTORS
Number of inputs 1
Number of outputs 3
Connector Type F-female (IEC 61 169-24)
