Ανεμιστήρας 230V AC 92x92x38mm 3656 EBM-Papst

Technical description

General description AC voltage fan with external rotor shaded-pole motor. Protected from overload by impedance protection. Fan housing and fan impeller made of metal. Air exhaust over bars. Rotational direction clockwise looking at rotor. Electrical connection to 2 single strands. Strand ends bared and tin-plated. Fan housing with grounding lug and tapping screw M4 x 8 (TORX). Mass 420 g. Please note our new ACmaxx series. With identical fastening dimensions and voltages, this series achieves higher energy efficiency.

Mass 0.420 kg
Dimensions 92 x 92 x 38 mm
Material of impeller Metal
Housing material Metal
Direction of air flow Air exhaust over bars
Direction of rotation Right, looking at rotor
Bearing Ball bearings
Lifetime L10 at 40 °C 52500 h
Lifetime L10 at maximum temperature 22500 h
Connection line 2 single strands AWG 18
Motor protection Protected from overload using impedance protection
Approval VDE, CSA, UL, CE
Current Type: AC
Supply Voltage: 230 V
Airflow: 44.1 CFM
Bearing Type: Ball
Noise: 37 dBA
Speed: 2700 RPM
Power Rating: 12 W
Termination Style: Wire Leads
