Ανεμιστήρας 12V DC 60x60x25mm EB60251S1 sleeve Sunon
-19%
Προβολή
Specification
Fan type DC
Bearing type slide bearing
Operating voltage 4.5 ÷ 13.8V
Supply voltage 12V DC
Fans maximum flow rate 39.7m3/h
Noise level 33.5dBA
Rotational rate/speed 4500 (±15%)rpm
Power consumption 1.62W
Rated current 0.135A
Current and power consumption tolerance ±15%
Min. insulation resistance 500MΩ
Fan material thermoplastic
Enclosure material thermoplastic
Insulation class E
Static pressure 5.33mm H2O
Operating temperature -10...70°C
Leads 2 300mm leads, AWG26
Flammability rating UL94V-0
Fan motor brushless DC motor
Fan dimensions 60x60x25mm
Weight 57 gr
